DOD - ChemLogic Portable X (CLP X)
The ChemLogic Portable X gas detection system is a handheld life saver. It can be used in several applications for quick, low-level gas detection. The CLP X boasts an easy to use interface with a simple replaceable, inexpensive, chemlogic tape cartridge. While detecting gas at low levels, this portable gas monitor offers rechargeable gas detection at an affordable price. Perfect for confined space, exterior sampling, or during a spill cleanup, the CLPX is lightweight and durable handheld unit. Rent one from us today to take care of all you gas detection needs!
| Detection Principle | ChemLogic Technology |
| Gas Families Available | See Table Below |
| Display | Back Lit LCD With Graphic Stain Development |
| Operating Temperature | 40°F - 95°F (4°C - 35°C) |
| Weight | 5.5 lbs |
| Operating Voltage | 6 VDC Battery or Charge, 100-240 VAC (50/60Hz) |
| Data Logging | 2 GB Micro SD Card |
| Dimensions | H-8.6” (219mm) W-4.1” (105mm) L-11.3”(287mm) |
CLPX Gas Calibrations
Hydrides
| Arsine (AsH3) | 0-50 ppb |
| Arsine (AsH3) | 0-500 ppb |
| Diborane (B2H6) | 0-1000 ppb |
| Germane (GeH4) | 0-2000 ppb |
| Hydrogen Selenide (H2Se) | 0-500 ppb |
| Hydrogen Sulfide (H2S) | 0-20 ppm |
| Phosphine (PH3) | 0-1500 ppb |
| Silane (SiH4) | 0-50 ppm |
Other
| Ammonia (NH3) | 0-75 ppm |
| Hydrazine (N2H4) | 0-500 ppb |
| Hydrogen Cyanide (HCN) | 0-2500 ppb |
| Ozone (O3) | 0-300 ppb |
| Phosgene (COCl2) | 0-90 ppb |
| Phosgene (COCl2) | 0-3000 ppb |
| Suflur Dioxide (SO2) | 24.9-2500 ppb |
| Nitrogen Trifluoride (NF3) | 1-50 ppm |
Mineral Acids
| Boron Trifluoride (BF3) | 0-5000 ppb |
| Hydrogen Bromide (HBr) | 0-20 ppm |
| Hydrogen Chloride (HCl) | 0-15 ppm |
| Hydrogen Fluoride (HF) | 0-10 ppm |
| Nitric Acid (HNO3) | 0-6000 ppb |
| Sufluric Acid (H2SO4) | 0-750 ppb |
Diisocyanates
| HDI | 0-200 ppb |
| HMDI | 0-100 ppb |
| IPDI | 0-200 ppb |
| MDI | 0-200 ppb |
| TDI | 0-200 ppb |
Oxidizers
| LL Chlorine (Cl2) | 0-20 ppb |
| Chlorine (Cl2) | 0-5000 ppb |
| Fluorine (F2) | 0-3200 ppb |
| Nitrogen Dioxide (NO2) | 0-25 ppm |
| Chlorine Dioxide (Cl02) | 0-1000 ppb |
Features:
- - Improved Optics Design
- - Immediate Alert Indicator Bar
- - Automated Calibration
- - Built In Data Logging
- - Real Time Clock with Date Stamp
- - SW Selectable Calibration Curves
- - Built In STEL
- - 2 Alarm Levels
- - Purged Cassette
Benefits
- - Provides Low Level GAs Detection in Seconds
- - Immediate Indication That Gas is Present
- - Eliminates Need for Optical Calibration
- - Micro SD CArd Records Up To 5 Years of Data
- - Accurate Recording of Data
- - All Calibrations are User Selectable - No Keys Needed
- - Up To 12 Hours of Continuous Monitoring
- - Unit Constantly Calculates for a Rolling 15 Min STEL
- - User Selectable Alarm Levels
- - Colorimetric Media Will Not Be Contaminated by Ambient Gas
