RAE Systems- QRAE Plus Multi-Gas Detector.
The QRAE Plus is a full-featured, compact, one-to-four sensor confined space gas detector. Its features include easy-to-change, externally accessed battery packs (available in both alkaline and rechargeable versions), internal vibrator alarm and water-resistant case design. The rechargeable, Lithium-ion battery pack provides up to 20 hours of continuous operation. The QRAE Plus includes 16,000 datalogging points of storage capacity for download to PC compatible with Windows 98, NT, 2000, and XP. This standard combustible gas sensor provides readings in the 0-100% LEL range, this unit has an optional combustible gas sensor which has a dual-mode that provides 0-100% LEL readings as well as 1-100% by volume range when operated in the "TC" (thermal conductivity) mode.
Monitor Only Includes:
- Shipping case
- Monitor as specified (Must be purchased/configured with at least 2 sensors)
- Sensors as specified
- Calibration adapter
- Quick reference guide
- Operation and maintenance manual
- Rubber boot with belt clip
- Alakline battery adapter
- Training on CD ROM
- Pumped Units additionally include: 3 External filters, Inlet probe (3") and External filter adapter
- Rechargeable units additionally include: Lithium-Ion battery pack with charger and Universal Wall adapter plug kit
QRAE Plus - Datasheet
QRAE monitors come standard with datalogging and include the following addtional accessories:
- Windows 95, 98, 2000, NT, ME & XP Compatible software
- Computer interface cable
Optional Accessories Kit adds:
- Hard Transport case with pre-cut foam
- 15 Foot Tygon tubing
- Constant flow hand pump (for diffusion models-NON-Pump)
- Tool Kit
Optional Calibration Kit adds:
*Note- Calibration Kit is only designed for QRAE Plus monitors with CO, H2S, LEL and O2 sensors installed.
- Four Gas CO,H2S,LEL,OX (Quad Mix) in a 29L cylinder
- Calibration (male) stainless steel regulator and tubing
(depending upon sensor/gas selection a non-stainless regulator may be provided)
- Accessories Kit
*Hazmat Shipping fee is included on Calibration Kits. Standard shipping rates will apply.
Other calibration gas configurations are available see our calibration gases page!
Applications:
| • | Confined Space Entry | |
| • | Waste water treatment plants | |
| • | Marine and off-shore oil wells | |
| • | Landfill operations | |
| • | Trenches, silos, railcars | |
| • | Coal mines | |
| • | Cruise ships | |
| • | Sewers and manholes | |
| • | Tunnels | |
| • | Refineries and petrochemical plants, including off-shore drilling and plant shut downs | |
| • | Power plants | |
| • | Pulp and paper industry | |
| • | Steel mills |
Key Features:
| • | One-to-four plug-in “smart” sensors: Combustible, Oxygen, Hydrogen Sulfide, Carbon Monoxide | |
| • | Optional substance-specific toxic sensors: Sulfur Dioxide (SO2), Nitric Oxide (NO), Nitrogen Dioxide (NO2), Chlorine (Cl2), Hydrogen Cyanide (HCN), Ammonia (NH3), Phosphine (PH3) | |
| • | Rechargeable Lithium-ion battery pack provides up to 20 hours (more than 2 work shifts) of continuous operation | |
| • | Rugged housing withstands use in harsh environments with a water and dust resistant case and strong protective rubber boot | |
| • | Highly resistant to radio frequency and other electromagnetic interference | |
| • | Strong, built-in sample draw pump with optional collapsible sample-probe | |
| • | Also available in diffusion configuration | |
| • | One-button calibration with auto-zero capability | |
| • | Loud audible alarm | |
| • | Bright visual alarm | |
| • | Interchangeable Lithium-ion and alkaline battery packs |
