MeshGuard - Gamma Detector

$1,910.00
SKU
RAED01-E110110

MeshGuard - Gamma Radiation Detector.

Connected, Intelligent Battery Powered Wireless Radiation Detection System-

The RAE Systems MeshGuard Gamma radiation detection monitor is a key building block of the MeshGuard intelligent network of connected sensors for gamma radiation detection in industrial and environmental monitoring applications. The MeshGuard system is designed for fast deployment in areas where low cost/high ROI solutions are required.

MeshGuard Gamma is available with field-replaceable pre-calibrated sensors specifically designed to sense X-ray and gamma radiation. It is also directly compatible with RAE Systems Meshguard wireless gas sensors for a fully integrated hazardous gas & radiation monitoring system. When coupled with ProRAE Guardian command center software, it provides a powerful real-time radiation and gas monitoring solution.

MeshGuard Gamma Unit Data Sheet








Applications:

  • Oil and gas drilling operations
  • Oil and gas production
  • Plant maintenance turnarounds
  • Industrial safety
  • Tank farms
  • Shipyards and maritime

Gamma MeshGuard Sensors:

Specifications
MeshGuard Sensor Range Energy Range Response Time-T90
Gamma 1 μR/h to 20 mR/h
(0.01 μSv/h to 200 μSv/h,
or 0.01 µGy/h to 200 µGy/h)
0.06 to 3.0 MeV
(X-Ray and
Gamma radiation)
T90  <  5 sec
(Dose Rate >1 mR/h,
10 µSv/h or 10 µGy/h)











MeshGuard Gamma Detectors Include:

  • MeshGuard Detector
  • CD-ROM with Operational Manual
  • High Capacity Lithium Battery
  • Maintenance Tool
  • Calibration Gas Adapter
  • Calibration Certificate
  • Antenna

Features:

  • Self-forming wireless network; units come online automatically
  • Compact and lightweight
  • IP-65 rated weather resistant, and splash guard equipped for sensor protection
  • Multiple controller options for real-time wireless data collection and viewing
  • Self-healing network automatically routes data back to controller through best wireless path available
  • Battery powered operation for up to 6 months
  • Intrinsically Safe
  • Magnetic mounting option for very quick and easy MeshGuard installation
  • Fully supported by the ProRAE Guardian software platform
