Honeywell Vertex Multi-Point Toxic Gas Monitoring System

Honeywell Analytics Vertex Multi-Point Toxic Gas Monitoring System.

Up to 72 points of continuous gas detection. Vertex combines the most advanced Chemcassette, software and optics technologies into a flexible, easy-to-use, reliable gas monitoring system.


Start your Vertex™ System with as little as eight points. As your monitoring needs change, Vertex™ expands, offering you up to 72 points of continuous gas detection. Place your sampling points up to 400 feet (120 meters) from the system. There is a choice of universal analyzer modules and/or pyrolyzer analyzers.

Honeywell Vertex Multi-Point Brochure


Vertex™ offers powerful, built-in system redundancy as standard equipment to effectively safeguard against downtime.

  • Back-up pump and internal power module
  • Chemcassette® technology provides physical evidence of gas event
  • System data back-up. If main data acquisition PC fails, analyzers continue to monitor, log data and alarm
  • Drip resistant cap for system protection from overhead leaks
  • Automated leak test with line integrity option

Easy to use

  • Touch screen for easy access to data
  • Software updates via CD-ROM or network to all system components
  • Configuration profile editing and data retrieval are all achievable without taking unit offline
  • Radio frequency identification tag (RFID) ensures Chemcassettes are installed into appropriately programmed analyzer, eliminating human error
  • On-line help system


  • Multiple levels of password protection
  • Reconfigure security setup without taking unit offline

Low cost of ownership

  • Vertex’s™ smaller footprint and greater density of points reduce your cost per point
  • Eight points per analyser lowers Chemcassette® costs
  • Maximized 72 point systems provide low cost per point as compared to other continuous monitors
  • One system monitors up to nine gas families and more than 40 gases
  • You can split your sample to more than one analyzer

Easy to maintain

  • Vertex™ uses cost-effective XP Chemcassettes®, providing up to three months of continuous monitoring
  • Simplified replacement of Chemcassettes® and automated optics verification
  • No dynamic calibration required
  • No flow balancing
  • Easy access to analyzers, pumps, power supplies and touch screen from front panel
  • Onscreen interactive electronic manual with integral video

Advanced communications

  • Built-in configurable PLCs with optional 176 relay contacts
  • Standard OPC interface for easy integration into your existing factory automation system or HMI
  • Optional Ethernet/CIP, LonWorks®, DeviceNetTM,
  • DF1 Interface, Profibus, Modbus Plus, Modbus/TCP,
  • ControlNet, or isolated 4-20mA outputs available
  • Optional Chemcam camera permits viewing of stain, locally or remotely, for proof of gas event. Image is electronically saved for future retrieval.
  • Optional remote control/viewing software enables total visualization of the monitor screens at a remote PC.
